The Invacare Action 3NG manual wheelchair is a sleek and stylish chair for everyday use. A highly versatile design enabling the wheelchair to be as modified as you need according to your functional and clinical requirements.
With a vast range of options and accessories available that are both quick and easy to reconfigure, the Action 3NG can easily be transformed from a more active set up to a more supportive set up if required. The perfect model for refurbishment and re-issuing with its cross compatible options and accessories that can be seen across the Action family and other Invacare product categories – Power Mobility, Rea Family, Active, Seating and Positioning and Alber.
Ideal for use at home or outdoors with great manoeuvrability from its multiple rear wheel positions and outstanding drive performance from its lightweight aluminum frame and new lightweight options. Making this manual chair easy to store and transport.
This versatile model can also be customised according to your personal taste with a choice of 8 vibrant frame colours. In combination with the sleek and modern black features that now come as standard across the Action range, including black nylon/mesh backrest upholstery and black front and rear wheels, the Action 3NG delivers on both functionality and aesthetics.
Along with the ability to fully adjust the configuration of the Action 3NG, it is also available in 6 standard configurations to make the ordering process as simple and easy to use as possible.
Key features
| Seat width: | 380 / 405 / 430 / 455 / 480 / 505 mm |
| Seat depth: | Self propel 400 / 450 / 500 mm / Transit 400 / 450 mm |
| Seat angle: | 0° / 3° / 6° |
| Seat height: | Self propel 360 / 385 / 410 / 435 / 460 / 485 / 510 mm / Transit 460 / 485 / 510 mm |
| Backrest angle: | 0° / 7° / 0° – 30° / – 15° – +15° |
| Backrest height: | Self Propel 325 – 510 mm / Transit 380 – 460 mm |
| Front frame angle: | 80° / 0 – 75° / 90° |
| Length of footrests: | 200 – 400 / 330 – 460 / 440 – 510 mm |
| Armrest height: | 200 – 280 / 240 / 170 – 300 / 210 – 350 mm |
| Driving unit width: | Self Propel Seat width + 190 mm / Transit +160mm |
| Total width folded: | Self Propel 295 mm / Transit 260mm |
| Total height folded: | 795 – 1510 mm |
| Total length: | Self Propel 980 – 1105 mm / Transit 950 – 1050 mm |
| Total length without footrests: | Self propel 835 – 960 mm / Transit 710 – 910 mm |
| Total height: | Self propel 820 – 1050 mm / Transit 920 – 1050 mm |
| Max. safe slope: | 7° |
| Turning diameter: | 870 mm |
| Max. user weight: | 125 kg |
| Total weight: | Self propel 13.0 kg / Transit 13.5kg |
| Transport weight: | Self propel 7.1 kg / Transit 10.3kg |
| Crash tested: | Yes |
| Frame colour: | Hypnotic Purple, Matt Black, Blue Pop, Matt Red, Pearl White, Slate Grey, Electric Green, Anthracite Black |
| Colour (other): | Upholstery: Black Nylon |
 |
Action 3NG Brochure (2.28 MB) |
|
Action One Solution brochure (1.13 MB) |
|
User Manual Action3 NG (ENG) (22.26 MB) |
