The Invacare Action 1R is a dependable, entry-level manual wheelchair designed for everyday use—without compromising on functionality or comfort. Backed by decades of experience in wheelchair design, it’s ideal for clients who need a straightforward, ready-to-go mobility solution. Action 1R is part of our highly established Action range of wheelchairs.
Available in two configurations
With six standard seat width options and a user-friendly design, the Action 1R can be quickly issued and easily adjusted to meet individual needs. It also features an optional elevating legrest for individuals requiring additional support and comfort.
Key features
Whether for short-term or longer-term use, the Action 1R offers a practical, comfortable, and efficient solution for basic mobility needs.
| Seat width: | 380, 405, 430, 455, 480, 505mm |
| Seat depth: | 400 – 430mm |
| Seat angle: | 3 degrees |
| Seat height: | 495mm |
| Backrest angle: | 0 / 7 degrees |
| Backrest height: | 430mm |
| Front frame angle: | 70 degrees |
| Length of footrests: | 330 – 455mm |
| Armrest height: | 240mm |
| Driving unit width: | Self propel version: 608 – 700mm (seat width +195mm) / Transit version: 578 – 670mm (seat width +160mm) |
| Total width folded: | Self propel version: 250mm / Transit version: 260mm |
| Total length inc. footrests: | Self propel version: 1085 – 1125mm / Transit version: 955mm |
| Total length without footrests: | Self propel version: 835 – 875mm / Transit version: 710mm |
| Total height: | 995mm |
| Max. safe slope: | Max. slope parking brake: 7° / Static stability downhill: 18° / Static stability uphill: 9° / Static stability sideways: 19° |
| Max. user weight: | 125kg |
| Total weight: | From 17.5kg |
| The heaviest part: | From 10.2kg |
| Crash tested: | Yes |
| Frame colour: | Anthracite Black |
1. Stability Values
2. Radius
3. Folded Dimensions
4. Overall dimensions
In some configurations, overall width or length exceed the authorised limits, access to emergency escape routes is not possible.
